AC15CD350AT2S AC Electronics Current Select LED Driver – 250/300/350mA Match-Book-Fast Shipping

Description

AC Electronics Constant Current Selectable LED Driver, 120-277V input, Multi-Switching Current 15W 350mA or 12.6W 300mA or 10.5W 250mA, 25-42V output, 0-10V dimming, Side Exit Leads.

AC Electronics Constant Current LED Driver

With the use of screwdriver , easily adjust the current to allow for 15, 12 or 10 watts of power.

Side Mount Leads

Selectable Max Output Power/Fixed Output Current: 15W/300mA 12.6W/300mA 10.5W/250mA

Output Voltage: 25-42V

Input Voltage: 120-277V

Input Frequency: 50-60hz

0-10V Dimming

Dimmable Range: 100-5%

Class P Listed

Class A Sound Rating

Use only with in enclosure

Surge Protection 2Kv

Approved Dimmers: Lutron NTSTV-DV, Leviton IP710 DL, Lutron NFTV, Watt Stopper ADF 120277

Spec Sheets

AC Electronics AC15CD350AT2S Specs
