EUM-030S050DT Inventronics Constant-Current-Programmable LED Driver – 30W 350mA Dimmable-Fast Shipping

Description

Inventronics EUM-030S050DT Programmable Constant Current LED Driver, 30W Max Power Output, Universal 120-277V Input, Programmable Output Current 300-500mA (factory default 350mA), 30-100V Output, Analog 0-10V and PWM Dimmable

Inventronics 30W 1050mA Constant Current LED Driver

Programmable, Enabling Hundreds of Configurations 300-500mA (factory default 350mA)

Compact Metal Case with Excellent Thermal Performance

Dimming Controls: Isolated 1-5V/1-10V/10V PWM/3-Timer-Modes Dimmable

Input Surge Protection: DM 6kV, CM 10kV

Output Lumen Compensation

Class 2 and SELV Output

IP66 / IP67 and UL Dry / Damp / Wet Location

TYPE HL, for use in a Class I, Division 2 hazardous (Classified) location

UL Class P

Spec Sheets

Inventronics EUM-030S050DT Specs
