EUM-075S105DT Inventronics Constant-Current-Programmable LED Driver – 75W 700mA Dimmable-Fast Shipping

Description

Inventronics Programmable Constant Current LED Driver, 75W Max Power Output, Universal 120-277V Input, Programmable Output Current 700-1050mA (factory default 700mA), 36-107V Output, Analog and PWM Dimmable

Inventronics 75W 700mA Constant Current LED Driver

Programmable, Enabling Hundreds of Configurations 700 to 1050mA (factory default 700mA)

Compact Metal Case with Excellent Thermal Performance

Dimming Controls: Isolated 1-5V/1-10V/10V, PWM, 3-Timer-Modes

Input Surge Protection: DM 6kV, CM 10kV

Output Lumen Compensation

Class 2 and SELV Output

IP66 / IP67 and UL Dry / Damp / Wet Location

TYPE HL, for use in a Class I, Division 2 hazardous (Classified) location

UL Class P

Spec Sheets

Inventronics EUM-075S105DT Specs
