KTLD-30-UV-SC1050-56-VDIM-U7 Keystone Programmable LED Driver – 30W 1050mA Dimmable-Fast Shipping

Description

Keystone SmartCurrent Constant Current Driver, 30W Max Power Output, Universal 120-277V Input, Programmable Fixed Output Current 350-1050mA (factory set 1050mA), 10-56Vdc Ooutput, Analog 0-10V Analog Dimming, IP20 dry and damp locations.

Keystone 30W Constant Current Programmable LED Driver

Features

Output Power 30 Watt

Output Current: 350-1050mA (factory set 1050mA) in 10mA increments

Output Voltage 10-56Vdc

Minimum Dimming Level: 1%, 3%, 5%,7%, or 10% (factory set 1%)

Dimming Curve: Linear, Log, Inverse Log, or Square-law (factory set Linear)

Auxiliary Power: 12Vdc; 200mA Max

UL Class P, Meets FCC 47 CFR Part 15 (Class B) Consumer Limits

Short Circuit Overload and Open Load Protection

Type 1 Outdoor, Suitable for Dry and Damp Locations

In field programming of fixed output current, dim level and curve type is easy with an Android phone and USB (cable included) and Smart Current PC software. Start by downloading the Smart Current Driver Software then use the software to program the LED driver to the specifications that best suit your needs.

Spec Sheets

KTLD-30-UV-SC1050-56-VDIM-U7 Spec Sheet
