Description
LED40W-114-C0350-D Thomas Research Constant Current LED Driver, 40W Max Power Output, Universal 120-277V Input, Fixed 350mA Output Current, 38-114Vdc Output, 0-10V Analog Dimming
Thomas Research 40W Constant Current Power Supply – Dimming
“D” version: 2-wire dimmable model dims 100% to 10%. Two extra wires included on the output side: +Purple/-Gray. This model is offers 0-10V & Resistance dimming, compatible with most quality 0-10V dimmers.
Replaces the obsolete LED40W-114-C0350-M-D
Total Power: 40 Watts
Output Current: 350mA
Input Voltage: 100-277 VAC
Output Voltage: 38-114VDC
IP66, NEMA 4
High Power Factor:>0.90 @ full load
Black Magic Thermal Advantage Plastic Housing
Spec Sheets
Thomas Research LED40W-114-C0350-D Specs
