LNE-12V320WDAA Delta Constant-Power LED Driver – 320W Dimming-Fast Shipping

Description

Delta LNE-12V320WDAA Configurable Constant Power (Adjustable current and voltage) 320W LED Driver, Dimming, 90-305Vac input, adjustable 12Vdc and 22500mA output.

Delta 320W 22500mA / 12VDC Adjustable Dimming LED Driver

Programmable, Enabling Hundreds of Configurations – potentiometers to adjust output voltage & constant current (CC) level

Output Current Range: 11250-22500mA

Output Voltage Range: 6-12Vdc in CC mode and 10.8-13.5Vdc in CV mode

Dimming Controls: Analog (0-10V), PWM

IP67 and UL Dry/Damp Location

High surge immunity (common mode: 6kV, differential mode: 4kV)
