LNE-36V150WDAA Delta Constant-Power LED Driver – 150W Dimming-Fast Shipping

Description

Delta LNE-36V150WDAA Configurable Constant Power (Adjustable current and voltage) 150W LED Driver, Dimming, 90-305Vac input, adjustable 36Vdc and 4200mA output.

Delta 150W 4200mA / 36VDC Adjustable Dimming LED Driver

Programmable, Enabling Hundreds of Configurations – potentiometers to adjust output voltage & constant current (CC) level

Output Current Range: 2100-4200mA

Output Voltage Range: 18-36Vdc in CC mode and 33-40Vdc in CV mode

Dimming Controls: Analog (0-10V), PWM

IP67 and UL Dry/Damp Location

High surge immunity (common mode: 6kV, differential mode: 4kV)
